Applications
- Honey
- Ghee/ Butter
- Milk
- Fruit Pulp
- Sauce
- Sugar syrup
- Glycerine
- Corrosive Viscous chemical
- Solvent
- Pharmaceutical Application
- Food Grade Oils
Specification
| Capacity | 20LPM To 500LPM |
| Pressure | Max 10 Kg |
| Size | 1/2 Inch To 3 Inch BSP threaded end |
| Temperature | Max 80 C |
| Mounting | Horizontal Foot Mtg / Trolley Type |
| Driven | Direct Coupled / Gear Box / V belt Pulley |
| Sealing | Mechanical Seal / Oil Seal / Gland Packing |
| Gear Type | Spur / Helical |
| MOC of Gear & Shaft | Stainless Steel |
| MOC of Body & Cover | Stainless Steel |
| Bearing | DU – Bush |
