Description
Combines the Quality of Both Simplicity & Sturdiness in the 3-part Design wherein the Driven & Driven Gear Assembly dong with Bearing Are housed inside the Main-Body (Casing) Itself allowing the Achievement of both alignment & Accuracy Resulting a trouble-free Long Service Life
Applications
- Various Grade Of Oil Transfer
- Edible / Vegetable Oil Transfer
- Bio Oil Transfer
- Fish Oil Transfer
- Soya-Lecithin Transfer
- Lube oils Transfer / Lubrication
- Hydraulic Oil Transfer
- Waste Oil Transfer
- Furnace Oil (FO) Transfer
- Hot Oil Circulation
- Thermic Fluid Circulation
Specification
| Capacity | 20LPM To 5000LPM |
| Pressure | Max 25 Kg |
| Size | 1/2 Inch To 8 Inch |
| Temperature | Mqx 200 C |
| Mounting | Horizontal Foot Mtg / Trolley Type |
| Driven | Direct Coupled / Gear Box / V belt Pulley |
| Sealing | Mechanical Seal / Oil Seal / Gland Packing |
| Pressure relief Valve | Externally adjustable integral Relief valve |
| Gear Type | Spur / Helical |
| MOC of Gear & Shaft | EN-24 Harden & Ground |
| MOC of Body & Cover | Graded Caste Iron & Ground |
| Bearing | Deep Groove Ball Bearing ( 4 Nos ) |
